    歡迎來到,深圳市芬德電子科技有限公司官網！









    finder功率繼電器









    聯系電話：0755-84552800


    手機號碼：189-2606-1910










    Product









   熱門搜索：



  Motor automation equipment、
  Enclosure、
  Product 40 series、
  55 series、
  38 series、
  Series 80...

























    Power relay











    62finder power relay











    • 62finder power relay
      •














    62finder power relay
    功率繼電器 16A







    Power relay


    ? AC and DC coils


    ? magnetic bias blowing


    ? PCB installation or plug-in installation (Faston 187) or flange installation (Faston 250)


    ? no contact option, > 3mm contact gap


    ? led, mechanical indicator & test button options







    全國免費咨詢熱線：0755-84552800



























     model

      62.32/62.33
      62.32-0300/62.33-0300




     Contact specifications




     Contact configuration
     2 CO (DPDT)
     3 CO (3PDT)
     2 NO (DPST-NO), ≥ 3 mm*
     3 NOS (3PST-NO), ≥ 3 mm*




     Rated current / maximum peak current a
     16/30**
     16/30**




     Rated voltage / maximum switching voltage V AC
     250/400
     250/400




     Rated load AC1 VA
     four thousand
     four thousand




     Rated load ac15 (230 V AC) VA
     seven hundred and fifty
     seven hundred and fifty




     Single phase motor rating (230/400 V AC)
     0.8/—
     0.8/1.5
     0.8/—
     0.8/1.5




     Breaking capacity dc1:30/110/220 V A
     16/0.6/0.4
     16/1.1/0.7




     Minimum switching load MW (v/ma)
     1000（10/10）
     1000（10/10）




     Standard contact material
     AgCdO
     AgCdO




     Coil specification




     Nominal voltage (UN)
     V AC (50/60 Hz)
     6 - 12 - 24 - 48 - 60 - 110 - 120 - 230 - 240 - 400




     V DC
     6 - 12 - 24 - 48 - 60 - 110 - 125 - 220




     Rated power ac/dc/ VA (50 Hz) /w/w
     2.2/1.3
     3/3




     Operating range
     AC
     （0.8…1.1）UN
     （0.85…1.1）UN




     DC
     （0.8…1.1）UN
     （0.85…1.1）UN




     Holding voltage ac/dc
     0.8 UN / 0.6 UN
     0.8 UN / 0.6 UN




     Required voltage ac/dc
     0.2 UN / 0.1 UN
     0.2 UN / 0.1 UN
