| model | fourteen point zero one | fourteen point seven one | fourteen point eight one | fourteen point nine one | ||||||||||
| Contact specifications | ||||||||||||||
| Contact configuration | 1 no (SPST-NO) | 1 no (SPST-NO) | 1 no (SPST-NO) | 1 no (SPST-NO) | ||||||||||
| Rated current / maximum peak current a | 16/30（120 A - 5 ms） | 16/30（120 A - 5 ms） | 16/30（120 A - 5 ms） | 16/30（120 A - 5 ms） | ||||||||||
| Rated voltage / maximum switching voltage V AC | 230/— | 230/— | 230/— | 230/— | ||||||||||
| Rated load AC1 | VA | three thousand and seven hundred | three thousand and seven hundred | three thousand and seven hundred | three thousand and seven hundred | |||||||||
| Rated load ac15 (230 V AC) | VA | seven hundred and fifty | seven hundred and fifty | seven hundred and fifty | seven hundred and fifty | |||||||||
| Nominal tube rating: 230 V incandescent / halogen w | three thousand | three thousand | three thousand | three thousand | ||||||||||
| Fluorescent tube with electronic voltage regulator w | one thousand and five hundred | one thousand and five hundred | one thousand and five hundred | one thousand and five hundred | ||||||||||
| Fluorescent tube with electromagnetic regulator w | one thousand | one thousand | one thousand | one thousand | ||||||||||
| CFL spiral fluorescent economizer bulb w | six hundred | six hundred | six hundred | six hundred | ||||||||||
| 230 V LED W | six hundred | six hundred | six hundred | six hundred | ||||||||||
| LV halogen lamp or LED, connected with electronic voltage regulator w | six hundred | six hundred | six hundred | six hundred | ||||||||||
| LV halogen lamp or LED, connected to electromagnetic regulator w | one thousand and five hundred | one thousand and five hundred | one thousand and five hundred | one thousand and five hundred | ||||||||||
| Minimum switching load | mW（V/mA） | 1000（10/10） | 1000（10/10） | 1000（10/10） | 1000（10/10） | |||||||||
| Standard contact material | AgSnO2 | AgSnO2 | AgSnO2 | AgSnO2 | ||||||||||
| Power supply specification | ||||||||||||||
| Nominal voltage (UN) | V AC（50/60 Hz） | two hundred and thirty | two hundred and thirty | 110…125/230 | two hundred and thirty | |||||||||
| V DC | — | — | — | — | ||||||||||
| Rated power | VA（50 Hz）/W | 3/1.2 | 3/1.2 | 3/1.2 | 3/1.2 | |||||||||
| Operating range | AC（50 Hz） | （0.8…1.1）UN | （0.8…1.1）UN | （0.8…1.1）UN | （0.8…1.1）UN | |||||||||
| DC | — | — | — | — | ||||||||||
